Encoder Settings
Recommended Streaming Software - VMIX or OBS
1080pHD30FPS (must have at least 5-10mbps upload speed)
Resolution - 1920x1080
Bitrate - 2500 - 4000max
FPS - 30fps
Encoder - x264 / (NVENC if available)
Keyframe Interval - 2
CPU Usage - Veryfast/Faster (The higher less CPU usage)
Preset - Quality/performance (Only if NVENC is available)
Profile- Main
Rate Control - CBR
Audio Sample Rate - 44kHz or 48kHz
Audio Channel - Stereo
Audio Bitrate - 160 or 192
720pHD30/24FPS (must have at least 8mbps upload speed)
Resolution - 1280x720
Bitrate - 1500 - 2500Kbps
FPS - 30
Encoder - x264 / (NVENC if available)
Keyframe Interval - 2
CPU Usage - Veryfast/Faster (The higher less CPU usage)
Preset - Quality/performance (Only if NVENC is available)
Rate Control - CBR
Audio Sample Rate - 44kHz
Audio Channel - Stereo
Audio Bitrate - 160
